X-TubeProcessor®_Smart 2.0

Automate your tube, dispensing, and labeling workflows

The X-TubeProcessor®_Smart 2.0 combines dispensing, capping/decapping, and labeling in a single compact system. It is designed for laboratories requiring flexible, reproducible processing of tubes and vials with reduced manual handling and full workflow control.

The system processes tubes and vials from 0.5–15 ml without gripper change, including cryovials, biobank tubes, HPLC vials, and FACS tubes, enabling flexible mixed-format workflows in a single run.

By integrating all key process steps into one platform, the X-TubeProcessor®_Smart 2.0 enables efficient end-to-end sample processing in a controlled, automated workflow.

Integrated 3-in-1 workflow

Dispensing, capping, and labeling in one system

The X-TubeProcessor®_Smart 2.0 integrates three core process steps: automated dispensing and filling, automated capping and decapping, and high-resolution labeling.

Depending on application requirements, the system can be configured with either a peristaltic pump for fast media changeovers and contact-free dispensing, or a micro annular gear pump for high-precision dosing and process stability.

Both pump systems are managed via the integrated DosingPumpManager, which handles priming, cleaning, and calibration functions.

Traceability and control

Full sample tracking with TwinCode and X-Control

TwinCode enables tube-specific identification using combined bottom and side barcode reading, ensuring full traceability of each sample throughout the workflow.

The X-Control software platform provides centralized workflow management with:

  • Job and process control
  • User and role management
  • Audit trail and logging
  • Exportable process data

The system supports integration into LIMS and ERP environments via REST API for fully digital workflows. The X-TubeProcessor®_Smart 2.0 is a modular system designed to adapt to evolving laboratory requirements while maintaining a fully integrated workflow for dispensing, capping and labeling.

Product features

High-Throughput

The X-TubeProcessor®_Smart 2.0 can hold 2 racks of 96 tubes or 4 racks of 48 tubes and handle up to 600 tubes per hour.

Operation

The X-TubeProcessor®_Smart 2.0 is a small footprint system that operates on compressed air.

Total Automation

The X-TubeProcessor®_Smart 2.0 includes a cap feeder to help create a seamless, automated workflow.

Modular System

The X-TubeProcessor®_Smart 2.0 is a modular system that can (de)cap, label, fill, and identify a variety of tubes.

  • Size 31.5" (L) x 22.8" (W) x 23.6" (H)
  • Weight 154.3 lbs
  • Throughput for capping 96 tubes 10 minutes
  • Throughput for filling + capping 96 tubes 15 minutes
  • Throughput for filling, capping, + labeling 96 tubes 25 minutes
  • Serial processing available
